The Super Mobile S30 Concrete Batching Plant excels with its 30 m³/h production capacity, rapid installation, and minimal space requirements for installation. Its compact design makes it ideal for container transportation, offering flexibility and ease of transport.
The Super Mobile S30 Concrete Batching Plant features a 0.5 m³ capacity pan mixer or an optional 0.5 m³ planetary mixer. It can be installed and ready to start concrete production in an exceptionally short time—just 2-3 hours. Its minimal site requirements and ability to be installed on zero ground are key advantages, making it an efficient and flexible solution for various project needs.
The Super Mobile S30 Concrete Batching Plant, specially designed for concrete projects that require continuous mobility, can be conveniently shipped in a 40' Open Top container, fully equipped with all necessary components. This design ensures easy transportation and setup for projects on the move.
The Super Mobile S30 Concrete Batching Plant offers low operation and maintenance costs, making it an appealing option for projects with a production requirement of 30 m³/hour. Equipped with a Fully Automatic Control System featuring PLC, the S30 ensures consistent, high-quality concrete production with precision and efficiency.
|
Technical Specifications S30 |
|
|
Compacted Concrete Output |
30 m³/h |
|
Mixer Capacity (Compacted Concrete) |
0,5 m³ / Cycle |
|
Mixer Type |
MEKA Pan Mixer |
|
Mixer Motor Power |
18,5 kW |
|
Aggregate Bins |
4x 2,5 m³ / CT (Cross Type) |
|
Aggregate Feeding |
From Ground Level |
|
Aggregate Transfer |
Belt |
|
Air Compressor |
Piston Type (4 kW) |
|
Cement Weighing Hopper |
300 kg |
|
Water Weighing Hopper |
160 kg |
|
Additive Weighing Hopper |
15 kg |
|
Cement Screw Conveyor |
Ø 193 x 5.000 mm |
