If concrete production capacity is your priority, the K160 Stationary Concrete Batching Plant delivers professional power, meeting all your needs for uninterrupted, high-capacity production even under the most challenging conditions.
With its powerful 4.0 m³ capacity MEKA twin-shaft mixer, the K160 offers the flexibility to produce any type of concrete—whether ready-mixed, roller compacted concrete (RCC), or precast concrete—and is fully customizable to meet your specific needs.
The K160 stands out with its standard 4x25 m³ bunker capacity, along with high-capacity bunker options to further support your production speed. Additionally, the two independently controllable pneumatic discharge gates per compartment in the aggregate bunker enhance speed and production efficiency, maximizing your potential for profit.
|
Technical Specifications K160 |
|
|
Compacted Concrete Output (Mixing Time : 30 seconds/ 20 seconds) |
160 m³/h |
|
Mixer Capacity (Compacted Concrete) |
4,0 m³ / Cycle |
|
Mixer Type |
TS (Twin Shaft) |
|
Mixer Motor Power |
2x75 kW |
|
Aggregate Bins |
4x 25 m³ / IT (T Type) 4x 35 m³ / IT (T Type) |
|
Aggregate Feeding |
Ramp or Pre-Feeding System |
|
Aggregate Transfer |
Belt |
|
Air Compressor |
Piston Type (7,5 kW) |
|
Cement Weighing Hopper |
2.250 kg |
|
Water Weighing Hopper |
1.200 kg |
|
Additive Weighing Hopper |
60 kg |
|
Cement Screw Conveyor |
Ø 323x 12.000 mm |
